1U Rackmount Power Strip with 12 Outlets and
15-ft. Cord
MODEL NUMBER: RS-1215
Description
Tripp Lite's RS-1215 Power Strip offers 15 amp capacity AC power distribution in a versatile multi-mount cabinet.
Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses
only 1 rack space (1U) when installed in any 19 inch rack meeting EIA standards. Unfiltered electrical
pass-through makes RS-1215 ideal for distributing alternate waveform UPS or generator power in rack
Highlights
Designed for standard 19-inch
racks (1U high)
12 outlets (6 front / 6 rear)
15-amp circuit breaker
15 ft. cord
Applications
Offers multiple outlet power
distribution for multiple loads in
19 inch rackmount, wallmount
and under-counter applications,
such as internetworking, PC
systems, telecommunications,
audio/video, security, sound
reinforcement and more. Ideal
for distribution of UPS, generator
or commercially derived AC
power to protected equipment.
Package Includes
RS-1215
Mounting hardware
Instruction manual
enclosures, network closets and more. Includes 12 NEMA5-15R outlets (6 front/6 rear), 15 ft AC power cord and
lighted switch with cover prevents risk of accidental turn-off.
PLUG/OUTLETS: Input: NEMA 5-15P
Output: 12 NEMA5-15R (6 front & 6 rear)
ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires standard NEMA 5-15R wall receptacle)
FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more
Features
Versatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options
Uses one rack space (1U) in standard 19 inch rack ("zero U" mounting possible in many racks)
Unfiltered electrical pass-through reliably distributes alternate waveform AC power from UPS or generator to supported equipment
12 NEMA5-15R output receptacles (6 front/6 rear)
15 foot AC cord NEMA5-15P plug connection
Lighted power switch confirms power on/off status
Snap-in switch guard prevents accidental turn off
15 amp electrical capacity with circuit breaker
120V AC, 50/60Hz electrical compatibility
Specifications
1 / 3
